Commercial Twin Tank Gas Fryer | Deep Fat Fryer | 2x14kg Capacity | Pitco SG14TS

STANDARD SPECIFICATIONS

CONSTRUCTION
„ Seperate welded tank design.
„ Welded tank with an extra smooth peened finish ensures easy cleaning.
„ Long-lasting, high-temperature alloy stainless steel heat baffles are mounted in the heat exchanger tubes to provide maximum heating and  combustion efficiency.
„ Standing pilot light design provides a ready flame when heat is required.
„ Stainless steel front, door, side, and  splashback.
„ Heavy duty 3/16” (.48 cm) door hinge.

CONTROLS
„ Millivolt thermostat maintains selected temperature
automatically between 200°F (93°C) and  400°F (190°C-CE).
„ Integrated gas control valve acts as a manual and  pilot valve,
automatic pilot valve, gas filter, pressure regulator, and
automatic main valve.
„ Gas control valve prevents gas flow to the main burner until
pilot is established and  shuts off all gas flow automatically if
the pilot flame goes out.
„ Temperature limit switch safely shuts off all gas flow if the
fryer temperature exceeds the upper limit.
„ New Solstice burner/baffle design.***
-Increases cooking production.
-Lowers flue temperature.
-Improves working environment.
-Generates more production per BTU.
***Compared to previous models.

OPERATIONS
„ Two front 1 1/4” (3.2 cm) full port drains for quick draining.
„ 9” (22.9 cm) clearance allows for ease of cleaning.

Solstice burner technology makes this PitcoSG14TS Twin Tank Gas Fryer one of the most efficient in its class.

Inside the fryer's heat exchange tubes are stainless steel baffles that maximize the transfer of heat from the burner to the oil. Another benefit to this system is that it helps reduce how much heat escapes through the fryer's flue, so the fryer does its part in keeping ambient kitchen temperatures comfortable. The unit's exterior cabinet is built with a stainless steel front, door, and sides. The heavy-duty door is mounted on a 3⁄16 inch hinge to prevent sagging.
